Silent Knight | IFP-2100

Silent Knight IFP-2100 Intelligent Fire Alarm Control Panel

The Silent Knight IFP-2100 is an advanced, intelligent addressable fire alarm control panel (FACP) designed to provide comprehensive fire protection for large-scale facilities. It supports robust networking capabilities, allowing interconnection of up to 32 panels to cover expansive areas or multiple buildings.

Key Features:

• Expandable Point Capacity: The IFP-2100 comes with one built-in Signaling Line Circuit (SLC) that supports up to 159 System Sensor IDP/SK detectors and 159 IDP/SK modules, or 127 Hochiki SD devices. Additional SLC loops can be added using the model 6815 SLC expander for IDP/SK devices, increasing the overall point capacity to 2,100 points per panel.

• Networking Capability: Supports the interconnection of up to 32 panels, enabling system expansion across large buildings or multiple facilities. The system can operate in two modes: as a unified system covering a large area or as multiple independent systems.

• Built-in Dual Path Communication: Equipped with a built-in digital alarm communicator/transmitter (DACT) that supports both IP and POTS (Plain Old Telephone Service) for reliable communication with central monitoring stations. Optional cellular reporting is also available.

• Flexput™ Circuits: Includes eight onboard Flexput™ circuits that can be configured as notification outputs or auxiliary power, providing flexibility in system design.

• Advanced Detection Features: Offers detector sensitivity adjustment, day/night thresholds, drift compensation, pre-trouble maintenance alerts, and calibration trouble alerts to ensure optimal performance and timely maintenance notifications.

Specifications:

• Dimensions: 16.4 inches (41.66 cm) width × 26.4 inches (67.06 cm) height × 4.1 inches (10.41 cm) depth

• Weight: 33 lbs. (15 kg)

• Operating Temperature Range: 32°F to 120°F (0°C to 49°C)

• Humidity Range: Up to 93% relative humidity (non-condensing)

• Color Options: Available in red or black cabinet

Compatibility:

The IFP-2100 is compatible with a wide range of addressable devices, including System Sensor IDP/SK series detectors and modules, as well as Hochiki SD protocol devices. It supports various modules and accessories to enhance system functionality, such as remote annunciators, LED I/O modules, relay interfaces, and printer interfaces.
