Notifier | FRM-1

Notifier FRM-1 Relay Control Module

The Notifier FRM-1 is an intelligent, addressable relay control module designed for use in two-wire systems. It allows a compatible control panel to switch discrete contacts via code command, enabling the activation of auxiliary devices such as fans, dampers, or control equipment. The module contains two isolated sets of Form-C (DPDT) contacts and features a panel-controlled LED indicator for status monitoring.

Key Features:

• Addressable Control: Enables the control panel to operate two isolated sets of Form-C contacts, facilitating the activation of various auxiliary devices.

• Panel-Controlled LED Indicator: Provides visual status indication, aiding in system monitoring and diagnostics.

• Rotary Address Switches: Allows for easy and precise module addressing within the system.

Specifications:

• Operating Voltage: 15 to 32 VDC

• Maximum Current Draw: 6.5 mA (LED on)

• Dimensions: 4.675” H x 4.275” W x 1.4” D

The FRM-1 is compatible with Notifier’s intelligent fire alarm control panels and mounts directly to standard 4-inch square electrical boxes with a minimum depth of 2 1/8 inches. Its design ensures reliable performance in various environmental conditions, with an operating temperature range of 32°F to 120°F (0°C to 49°C) and humidity tolerance from 10% to 93% non-condensing.
